- SD-Format-Unterstützung: 525/29.97 NTSC, 525/23.98 NTSC, 625/25 PAL
- HD-Format-Unterstützung: 720p59.94, 720p60, 1080i50, 1080i59.94,
1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30,
1080p50, 1080p59.94, 1080p60
- 4K-Format-Unterstützung: 3840x2160p23.98, 3840x2160p24,
3840x2160p25, 3840x2160p29.97, 3840x2160p30, 4096x2160p24
- SDI-Konformität: SMPTE 292M, SMPTE 259M, SMPTE 296M, ITU-R BT.656
und ITU-R BT.601.
- SDI-Audioabtastfrequenz: Standard-Fernsehabtastrate von 48 kHz
und 24 Bit.
- SDI-Videoraten: SDI-Anschlüsse sind zwischen Standard Definition
und High Definition umschaltbar.
- SDI-Videoabtastfrequenz: 4:2:2
- SDI-Farbgenauigkeit: 10-Bit
- SDI-Farbraum: YUV
- Automatische SDI-Umschaltung
- Automatische Auswahl zwischen SD SDI, HD-SDI und 6G-SDI.
- HDMI-Farbgenauigkeit 4:2:2 und 4:4:4
- HDMI-Farbraum: YUV
- HDMI-Format-Unterstützung: 625/25 PAL, 525/29.97 NTSC, 525/23.98
NTSC, 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60,
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50,
1080p59.94, 1080p60, 2048x1080p23.98, 2048x1080p24, 2048x1080p25,
3840x2160p23.98, 3840x2160p24, 3840x2160p25, 3840x2160p29.97,
3840x2160p30, 4096x2160p24
- Kopierschutz: Die Aufnahme von kopiergeschützten HDMI-Quellen ist
über den HDMI-Eingang nicht möglich. Vergewissern Sie sich vor
der Erfassung oder Verbreitung von Inhalten immer über das
Urheberrecht.
